Quick Details

  • Condition: New
  • Type: Drum Drying Equipment
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: Nanbei
  • Model Number: NBFD series
  • Voltage: 220V
  • Power(W): 5.5kw
  • Dimension(L*W*H): 582x625x530mm
  • Weight: 100kg
  • Certification: ISO
  • Warranty: 1 Year
  • After-sales Service Provided: No overseas service provided
  • Name: Home vacuum food freeze dryer price for sale
  • Cold trap no load temperature: ≤-56C
  • Vacuum degree: 10 Pa
  • Freeze drying area: 0.12~0.18m2
  • Water catching capacity: 3kg/24h
  • Product load: 900ml
  • pan size: 200x20
  • pan layers: 2
  • freeze drying time: 24h
  • Dimension: 582*625*530mm

Packaging & Delivery

Packaging Details Wooden case Home vacuum food freeze dryer price for sale
Delivery Time Shipped in 7 days after payment

Home vacuum food freeze dryer price for sale

Product Description

 Freeze dryer is widely used in field of Biology pharmacy,Medical treatment,food etc. Such as in the production of biological products of BCG vaccine, epidemic cerebrospinal meningitis vaccine, measles vaccine, flu vaccine,; in the production of drugs, antibiotics, circulatory medication.In the field of medical treatment can be used in the long-term preservation of frozen blood, arteries, bones, skin, cornea and nerve tissue and other organs.



A series of laboratory lyophilized products are divided into basic type, gland type, manifold, manifold gland type.



The NBJ series of freeze dryers, manufactured by Creatrust, are specially designed in either table top or upright, which have compact structure, small footprint, reliable performance and competitive price for various laboratory use. There are four general types, “-S”, “-T”, “-P” and “-PT” and they can be used widely in biological engineering, pharmaceutical industry, food industry, material science and agriculture.



Freeze Dryer General Features

1. LCD touch screen display to show test curve and other necessary operational parameters

2. Standard USB interface

3. Low sound level

4. Stainless steel condenser and work station for easy cleaning and maintenance

5. Transparent acrylic drying chamber for easy observation of freezing and drying process

6. Compatible interface for different vacuum pumps connection

7. Various optional accessories





Model

NBJ-10S

NBJ-10T

NBJ-10P

NBJ-10PT

Final condenser temp (℃)

-55

-55

-55

-55

Vacuum Degree (Pa)

<10

<10

<10

<10

Freeze drying area (m2)

0.12

0.09

0.12

0.09

Ice condenser capacity (Kg/24h)

3

3

3

3

Qty of shelf

4

3

4

3

Material loading capacity/shelf (ml)

300

300

300

300

Material loading capacity (ml)

1200

900

1200

900

Freeze drying time (h)

24

24

24

24

Manifold

/

/

8 pieces

8 pieces

USB Interface

Y

Y

Y

Y

Control System

Microprocessor, touch screen

Power supply (V/Hz)

220V/50Hz,60Hz, 120V/60Hz

Exterior dimension (WxDxH mm)

472*558*438/885

Note

Shelf heating function is optional;
Accessories for different chamber and manifold are optional;
The vacuum pump for evacuation is independent and packed in a separate package.



Pictures

NBJ-10SNBJ-10T
NBJ-10PNBJ-10PT
Packaging & Shipping

 Package : Wooden case

Shipping : 7~10days after payment
