Electric high speed impact digital torque tester

FOB Reference Price:Get Latest Price
$655.00 - $1,186.00 / Set | 1 Set/Sets (Min. Order)
Usage:
Torsion Tester
Samples:
$952.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China
Brand Name:
NANBEI torque tester
Model Number:
AGN-20
Power:
Electronic
Product name:
Electric high speed impact digital torque tester
Measuring range / Division value:
20.000/ 0.001N.m
Measuring range / Division value2:
204.21/ 0.01Kg.cm
Measuring range / Division value3:
177.24/ 0.01 Lb.in
Size:
230*95*180mm
Net Weight:
8.5KG
Application:
pneumatic screwdriver, torque screwdriver, torque wrench torque
Type:
torque testing machine,analysis instrument,measurement device
Dimension:
230*70*125mm
Weight:
2kg
Supply Ability
Supply Ability:
1000 Set/Sets per Month Electric high speed impact digital torque tester
Packaging & Delivery
Packaging Details
Wooden case Electric high speed impact digital torque tester
Port
Qingdao

Electric high speed impact digital torque tester

Our Product

Application

Mainly used to detect and correct a variety of electric pneumatic screwdriver, torque screwdriver, torque wrench torque, a variety of products involved in the test of tightening force, parts to reverse the devastating test.

With simple operation, high precision, full function, easy to carry, and other characteristics, widely used in a variety of electrical, light industry, machinery manufacturing, scientific research institutions and other industries. The instrument has a print, without a printer

Main features
1:High precision, high resolution, quick sampling speed, full-screen display.
2: Adopting high precision torque sensor, with torque direction display
3:Upper and lower limit value setting, red and green indicating lights and buzzer audible and visual alarm.
4:Three units can be switched each other (N·m, kgf·cm, Lb·in).
5: Real-time, peak, automatic peak three models of optional switch.
6:Use USB interface and PC communications, synchronous test function can connect to the computer, computer
synchronous display test force graph and the detailed test process, can save, print, doing all sorts of analysis.
7: Peak holding, remove automatically function, remove time to set freely.
8: Large storage, can save 99 groups of test data.
9:Without automatic shutdown function, time can be set freely.

Picture for Our product

Electric high speed impact digital torque tester
Power port and USB portOperation Panel
SensorPackage



Technical data



  Type

Index

With printer

AGN-1P

AGN-2P

AGN-3P

AGN-5P

AGN-10P

AGN-20P

No printer

AGN-1

AGN-2

AGN-3

AGN-5

AGN-10

AGN-20

Measuring range /

 Division value

N·m

1.0000/

0.0001

2.0000/

0.0001

3.0000/

0.0001

5.0000/

0.0001

10.000/

0.001

20.000/

0.001

Kg·cm

10.210/

0.001

20.421/

0.001

30.631/

0.001

51.052/

0.001

102.10/

0.01

204.21/

0.01

Lb·in

8.862/

0.001

17.724/

0.001

26.586/

0.001

44.311/

0.001

88.62/

0.01

177.24/

0.01

Precision

±1%F.S

Peak Value Sampling Frequency

2000HZ

Power

8.4V  1.2VX7  Ni-MH Battery group

Charging Time

4~6 Hours

Continuous using time of battery

About 10 Hours

Battery life

≥300 times

Size

With printer:230mm×95mm×180mm

No printer:230mm×70mm×125mm

Net Weight

With printer:5KG     No printer:3KG

Power adapter

Input:AC 110-220V 50HZ   Output:DC 10V 300mA
